Main | Proteins | Meat proteins

Meat proteins

Pork skin protein (pork collagen)

Raw material:

  • Frozen pork skin

Process description:

At the beginning of the process incoming frozen pork skin crushes by heavy duty grinder to the small particles. The particles is first mixed with conditioned hot water in a mixing tank. The washing takes place continuously and the ratio of mince to water, as well as water temperature, is automatically monitored and precisely adjusted. The washed skin is then pumped to the decanter centrifuge for separation of water and washed particles, containing mostly proteins. Wet particles conveys to the fluid bed dryer to convert to the dry pork collagen. Optionally, a second washing stage may be implemented before drying. Dry particles should be milled and packed.
Stick water after decanter can be pumps to the waste water treatment or, optionally, concentrated at vacuum evaporation system and used as feed ingredient.

End products:

  • Pork skin protein (pork collagen);
  • Pork fat;

Scope of Supply:

Complete process including the following main components:

  • Washing unit;
  • Decanter centrifuges;
  • Centrifugal separators;
  • Valves and pumps;
  • Heat Exchangers;
  • Fluid bed dryer;
  • Mill;
  • Packaging system;
  • Instruments and controls.

pork skin espace

Beef bone extract

fleisch knochenmehl espace

Raw material:

  • Beef bone

Process description:

Food grade beed bone processing includes the following steps:

  • Bones crashing;
  • Mixing of bones with water and feed to cookers;
  • Retention of mixture in cookers;
  • Primery bullion clarification by decanter centrifuge;
  • Final bullion clarification and primary de-oiling by centrifugal separator;
  • Optional: enzymatic treatment;
  • Concentration of clarified bullion by vacuum-evaporation system;
  • Sterilization, cooling, dosing ingredients & packaging of liquid concentrated bullion;
  • Optional: spray drying of concenrated bullion;
  • Final tallow clarification by centrifugal separator;
  • Drying of residuals with bone-end-meat production;

End products:

  • Food grade beef bone protein extract in two alternatives:
    • Spray dried powder, packed into 20-25 kg bags;
    • Liquid concentrate (up to 70% TS), packed into 5-20 liters bag-in-box;

As alternative intermediate enzymes processing is available.

  • Clarified beef fat (tallow), food grade, cooled and packed in 20-25 kg boxes;
  • Dry meat-and-bone meal, packed  in 500-1000 kg big-bags;

Scope of Supply:

Complete process including the following main components:

  • Washing unit;
  • Decanter centrifuges;
  • Centrifugal separators;
  • Vacuum evaporation system;
  • Valves and pumps;
  • Heat Exchangers;
  • Spraydryer;
  • Packaging system;
  • Instruments and controls.
